Customers Sportster Gallery
note: increases in length shown below are
approximate
#196 1993
XL883 18 degree kit 10+ over tubes
Increase in length 12"
#195
2005 XL1200 14 degree kit 8+ over tubes
Increase in length 10"
#190
2005 XL1200c Trike 18 degree kit 8+ over tubes
Increase in length 11"
#187 2012 HARLEY
XL1200V
-
14 deg. rake kit w/ +6 " OS tubes.
Increase in length 9"
#183 2000 Nightster 1200 Trike 18deg.
rake kit w/+8" tubes.
Increase in
length 11"
#181 1994 XL 1200 Custom 9 deg.
rake kit w/+4" tubes.
Increase in length 5"
#177 2006 Harley XLC1200C 14 deg.
rake kit w/+8" tubes.
Increase in length 10"
# 171 2005 XL 1200 Custom 9 deg. rake kit w/+4"
tubes.
Increase in length 5"
.JPG)
2006 XL1200C 14 degree 6” os 41mm upgrade.
Increase in length 9"
2009 XL1200N 9 degree 2” os 41mm
upgrade.
Increase in length 4"
2004 Harley xl1200c 9 Deg. 4” os 41mm upgrade.
Increase
in length 5"
2005 XL 14 Deg.
4" os 39mm.
Increase in
length 8"
2004 Harley® XLC
14 degree with 6" os 41mm
Increase
in length 9"
2006 XL883L
9 deg. 2" os 41mm.
Increase
in length 4"
1997 XL1200S
14 deg. 6" os 41mm.
Increase
in length 9"
2007 XL1200N
Nightster 14 Deg. 2” os. 39mm
(4" or
6" os tubes would be a better choice)
Increase in length 7"
2004 XLC
14 Deg. 6” os 39mm.
Increase
in length 9"
2006 XL1200 14 Deg. 6" os 41mm.
Increase
in length 9"
2004 XL883 18 Deg. 10" os. 39mm.
Increase
in length 12"
2005 XLC with 14 Deg. kit, 6" Over Tubes
Increase
in length 9"
2007 XL1200C 14 degree
6" OS tubes
Increase
in length 9"
2002 XL1200N 14 degree
4" OS tubes.
Increase in length 8"
2004 XL 9 deg. 4" over stock tubes.
Increase
in length 5"
2004 1200 XLC 14 degree with
6" os 39mm.
Increase in
length 9"
2005 XLC 14 degree with
6" over stock 41mm.
Increase
in length 9"
2008 XL 14 degree with
8" os 39mm .
Increase in
length 10"
2003 XL 18 degree with
10" os 39mm.
Increase in
length 12"
2006 XLC 14 degree with 6" over stock
39mm.
Increase in length 9"
2006 XL 14 degree with 8" os. 39mm.
Increase
in length 10"
1999 XL Hugger 18 deg.
8" os. 39mm.
Increase in
length 11"
2000 XL 14 degree with 6" os. 41mm.
Increase in length 9"
2005 XL 1200 14 degree with
4" over stock tubes
2007 XL 14 degree with
8" over stock tubes
1999 Sportster XL 18 degree with
10" over stock tubes
2004 883XL 14 degree with
6" over stock tubes w/200mm
Wide Tire Kit
XL 9 degree with
4" over stock tubes
1998 XL Hugger 14 degree with
10" over stock tubes
2004 XL 14 degree with
6" over stock tubes
2002 XLC1200 14 degree with
8" o.s. w/41mm upgrade
2006 XLC 14 degree with 8" over stock tubes
2001 XL14 degree with
6"
over stock tubes
2001 XLC 14 degree with 8" over stock tubes
2003 XLC 14 degree with 8" over stock tubes
2004 XLC 14 degree with 6" over stock tubes
2001 XLC 14 degree with 8" over stock tubes
1977 XL 14 degree with 8" over stock tubes
2004 XL 14 degree with 8" over stock tubes
2004 XL 1200R 14 degree with 6" over stock tubes
2006 XLC 9 degree with 4" over stock tubes
1994 XL 18 degree with 8" over stock tubes
1990 XL 18 degree with 8" over stock tubes
2005 XLC 14 degree with 8" over stock tubes
2000 XLC 14 degree with 6" over stock tubes
1984 XL 14 degree with 41mm
upgrade 6" over stock tubes
2004 XLC 14 degree with 6" over stock tubes
2005 XLC 18 degree with 10" over stock
tubes
2003
1200C 41mm,
14 degree, 8" over stock tubes
2005
1200C 41mm,
14 degree, 8" over stock tubes
2004 XLC 9 degree with 4" over stock tubes
1977
XL
9 degree with 41mm with 4" over stock tubes
 2003 XL 14 deg. 8" over 39 mm tubes
2005 XLC 14 Deg. 6" over 39 mm tubes
 XL Custom 14 deg. 39 mm 8" over tubes
1997 XLC 14 deg. 41mm 8" over tubes, lowered rear
2005 883L 14 degree 8" over 39 mm tubes
 1996 XLH 14 deg. 8" over 39 mm tubes
2004 XLC 14 deg. 8" over 41 mm tubes
2006 883 XLH 14 deg. 8" over 41mm tubes
 1994 XL 14 deg. 8" over 39 mm tubes
XL 14 deg. 8" over 41mm tubes
1994 XL 14 deg. 8" over 41 mm tubes
2003 XL 1200 C, 14 deg. 8" over 39 mm tubes
2004 XL 1200 C 14 deg. 39mm 8" over tubes |
